k8s部署nacos

nacos.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79

---
kind: StatefulSet
apiVersion: apps/v1
metadata:
  name: nacos
  namespace: public
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nacos
  template:
    metadata:
      labels:
        app: nacos
    spec:
      containers:
        - name: nacos
          image: registry.cn-hangzhou.aliyuncs.com/iuxt/nacos-server:v2.1.0
          # image: nacos/nacos-server:v2.1.0       # 官方镜像地址
          ports:
            - name: client
              containerPort: 8848
              protocol: TCP
            - name: client-rpc
              containerPort: 9848
              protocol: TCP
            - name: raft-rpc
              containerPort: 9849
              protocol: TCP
            - name: old-raft-rpc
              containerPort: 7848
              protocol: TCP
          env:
            - name: NACOS_REPLICAS
              value: '3'
            - name: MYSQL_SERVICE_HOST
              value: 10.96.15.23
            - name: MYSQL_SERVICE_DB_NAME
              value: nacos
            - name: MYSQL_SERVICE_PORT
              value: '3306'
            - name: MYSQL_SERVICE_USER
              value: root
            - name: MYSQL_SERVICE_PASSWORD
              value: com.012
            - name: NACOS_SERVER_PORT
              value: '8848'
            - name: NACOS_APPLICATION_PORT
              value: '8848'
            - name: PREFER_HOST_MODE
              value: hostname
            - name: NACOS_AUTH_ENABLE
              value: 'true'

            # 这里的地址需要根据实际情况进行修改，用curl先测试
            - name: NACOS_SERVERS
              value: >-
                nacos-0.nacos-headless.public.svc.cluster.local:8848
                nacos-1.nacos-headless.public.svc.cluster.local:8848
                nacos-2.nacos-headless.public.svc.cluster.local:8848
          resources:
            requests:
              cpu: 500m
              memory: 2Gi
      dnsPolicy: ClusterFirst
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            - labelSelector:
                matchExpressions:
                  - key: app
                    operator: In
                    values:
                      - nacos
              topologyKey: kubernetes.io/hostname
      schedulerName: default-scheduler
  serviceName: nacos-headless
  podManagementPolicy: OrderedReady

nacos.sql

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241

SET NAMES utf8mb4;
SET FOREIGN_KEY_CHECKS = 0;

-- ----------------------------
-- Table structure for config_info
-- ----------------------------
DROP TABLE IF EXISTS `config_info`;
CREATE TABLE `config_info`  (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'data_id',
  `group_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `content` longtext CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'content',
  `md5` varchar(32) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'md5',
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '创建时间',
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '修改时间',
  `src_user` text CHARACTER SET utf8 COLLATE utf8_bin NULL COMMENT 'source user',
  `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip',
  `app_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT '租户字段',
  `c_desc` varchar(256) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `c_use` varchar(64) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `effect` varchar(64) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `type` varchar(64) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `c_schema` text CHARACTER SET utf8 COLLATE utf8_bin NULL,
  `encrypted_data_key` text CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT '秘钥',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_configinfo_datagrouptenant`(`data_id`, `group_id`, `tenant_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1485 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = 'config_info' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for config_info_aggr
-- ----------------------------
DROP TABLE IF EXISTS `config_info_aggr`;
CREATE TABLE `config_info_aggr`  (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'data_id',
  `group_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'group_id',
  `datum_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'datum_id',
  `content` longtext CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT '内容',
  `gmt_modified` datetime(0) NOT NULL COMMENT '修改时间',
  `app_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT '租户字段',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_configinfoaggr_datagrouptenantdatum`(`data_id`, `group_id`, `tenant_id`, `datum_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = '增加租户字段' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for config_info_beta
-- ----------------------------
DROP TABLE IF EXISTS `config_info_beta`;
CREATE TABLE `config_info_beta`  (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'data_id',
  `group_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'group_id',
  `app_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'app_name',
  `content` longtext CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'content',
  `beta_ips` varchar(1024) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'betaIps',
  `md5` varchar(32) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'md5',
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '创建时间',
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '修改时间',
  `src_user` text CHARACTER SET utf8 COLLATE utf8_bin NULL COMMENT 'source user',
  `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip',
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT '租户字段',
  `encrypted_data_key` text CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT '秘钥',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_configinfobeta_datagrouptenant`(`data_id`, `group_id`, `tenant_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = 'config_info_beta' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for config_info_tag
-- ----------------------------
DROP TABLE IF EXISTS `config_info_tag`;
CREATE TABLE `config_info_tag`  (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'data_id',
  `group_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'group_id',
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT 'tenant_id',
  `tag_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'tag_id',
  `app_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'app_name',
  `content` longtext CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'content',
  `md5` varchar(32) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'md5',
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '创建时间',
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '修改时间',
  `src_user` text CHARACTER SET utf8 COLLATE utf8_bin NULL COMMENT 'source user',
  `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_configinfotag_datagrouptenanttag`(`data_id`, `group_id`, `tenant_id`, `tag_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = 'config_info_tag' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for config_tags_relation
-- ----------------------------
DROP TABLE IF EXISTS `config_tags_relation`;
CREATE TABLE `config_tags_relation`  (
  `id` bigint(20) NOT NULL COMMENT 'id',
  `tag_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'tag_name',
  `tag_type` varchar(64) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'tag_type',
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'data_id',
  `group_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'group_id',
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT 'tenant_id',
  `nid` bigint(20) NOT NULL AUTO_INCREMENT,
  PRIMARY KEY (`nid`) USING BTREE,
  UNIQUE INDEX `uk_configtagrelation_configidtag`(`id`, `tag_name`, `tag_type`) USING BTREE,
  INDEX `idx_tenant_id`(`tenant_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = 'config_tag_relation' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for group_capacity
-- ----------------------------
DROP TABLE IF EXISTS `group_capacity`;
CREATE TABLE `group_capacity`  (
  `id` bigint(20) UNSIGNED NOT NULL AUTO_INCREMENT COMMENT '主键ID',
  `group_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL DEFAULT '' COMMENT 'Group ID，空字符表示整个集群',
  `quota` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '配额，0表示使用默认值',
  `usage` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '使用量',
  `max_size` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '单个配置大小上限，单位为字节，0表示使用默认值',
  `max_aggr_count` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '聚合子配置最大个数，，0表示使用默认值',
  `max_aggr_size` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值',
  `max_history_count` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '最大变更历史数量',
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '创建时间',
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '修改时间',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_group_id`(`group_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = '集群、各Group容量信息表' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for his_config_info
-- ----------------------------
DROP TABLE IF EXISTS `his_config_info`;
CREATE TABLE `his_config_info`  (
  `id` bigint(64) UNSIGNED NOT NULL,
  `nid` bigint(20) UNSIGNED NOT NULL AUTO_INCREMENT,
  `data_id` varchar(255) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL,
  `group_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL,
  `app_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'app_name',
  `content` longtext CHARACTER SET utf8 COLLATE utf8_bin NOT NULL,
  `md5` varchar(32) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0),
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0),
  `src_user` text CHARACTER SET utf8 COLLATE utf8_bin NULL,
  `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `op_type` char(10) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL,
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT '租户字段',
  `encrypted_data_key` text CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT '秘钥',
  PRIMARY KEY (`nid`) USING BTREE,
  INDEX `idx_gmt_create`(`gmt_create`) USING BTREE,
  INDEX `idx_gmt_modified`(`gmt_modified`) USING BTREE,
  INDEX `idx_did`(`data_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1683 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = '多租户改造' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for permissions
-- ----------------------------
DROP TABLE IF EXISTS `permissions`;
CREATE TABLE `permissions`  (
  `role` varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  `resource` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  `action` varchar(8) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  UNIQUE INDEX `uk_role_permission`(`role`, `resource`, `action`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_general_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for roles
-- ----------------------------
DROP TABLE IF EXISTS `roles`;
CREATE TABLE `roles`  (
  `username` varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  `role` varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  UNIQUE INDEX `idx_user_role`(`username`, `role`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_general_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for tenant_capacity
-- ----------------------------
DROP TABLE IF EXISTS `tenant_capacity`;
CREATE TABLE `tenant_capacity`  (
  `id` bigint(20) UNSIGNED NOT NULL AUTO_INCREMENT COMMENT '主键ID',
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL DEFAULT '' COMMENT 'Tenant ID',
  `quota` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '配额，0表示使用默认值',
  `usage` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '使用量',
  `max_size` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '单个配置大小上限，单位为字节，0表示使用默认值',
  `max_aggr_count` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '聚合子配置最大个数',
  `max_aggr_size` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值',
  `max_history_count` int(10) UNSIGNED NOT NULL DEFAULT 0 COMMENT '最大变更历史数量',
  `gmt_create` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '创建时间',
  `gmt_modified` datetime(0) NOT NULL DEFAULT CURRENT_TIMESTAMP(0) COMMENT '修改时间',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_tenant_id`(`tenant_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 1 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = '租户容量信息表' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for tenant_info
-- ----------------------------
DROP TABLE IF EXISTS `tenant_info`;
CREATE TABLE `tenant_info`  (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',
  `kp` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NOT NULL COMMENT 'kp',
  `tenant_id` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT 'tenant_id',
  `tenant_name` varchar(128) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT '' COMMENT 'tenant_name',
  `tenant_desc` varchar(256) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'tenant_desc',
  `create_source` varchar(32) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'create_source',
  `gmt_create` bigint(20) NOT NULL COMMENT '创建时间',
  `gmt_modified` bigint(20) NOT NULL COMMENT '修改时间',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE INDEX `uk_tenant_info_kptenantid`(`kp`, `tenant_id`) USING BTREE,
  INDEX `idx_tenant_id`(`tenant_id`) USING BTREE
) ENGINE = InnoDB AUTO_INCREMENT = 43 CHARACTER SET = utf8 COLLATE = utf8_bin COMMENT = 'tenant_info' ROW_FORMAT = Dynamic;

-- ----------------------------
-- Table structure for users
-- ----------------------------
DROP TABLE IF EXISTS `users`;
CREATE TABLE `users`  (
  `username` varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  `password` varchar(500) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL,
  `enabled` tinyint(1) NOT NULL,
  PRIMARY KEY (`username`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_general_ci ROW_FORMAT = Dynamic;

SET FOREIGN_KEY_CHECKS = 1;


INSERT INTO users (username, password, enabled) VALUES ('nacos', '$2a$10$EuWPZHzz32dJN7jexM34MOeYirDdFAZm2kuWj7VEOJhhZkDrxfvUu', TRUE);

INSERT INTO roles (username, role) VALUES ('nacos', 'ROLE_ADMIN');


/******************************************/
/*   ipv6 support   */
/******************************************/
ALTER TABLE `config_info_tag`
MODIFY COLUMN `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip' AFTER `src_user`;

ALTER TABLE `his_config_info`
MODIFY COLUMN `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL AFTER `src_user`;

ALTER TABLE `config_info`
MODIFY COLUMN `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip' AFTER `src_user`;

ALTER TABLE `config_info_beta`
MODIFY COLUMN `src_ip` varchar(50) CHARACTER SET utf8 COLLATE utf8_bin NULL DEFAULT NULL COMMENT 'source ip' AFTER `src_user`;

nacos-svc.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

apiVersion: v1
kind: Service
metadata:
  name: nacos-headless
  namespace: public
  labels:
    app: nacos-headless
spec:
  type: ClusterIP
  clusterIP: None
  ports:
    - port: 8848
      name: server
      targetPort: 8848
    - port: 9848
      name: client-rpc
      targetPort: 9848
    - port: 9849
      name: raft-rpc
      targetPort: 9849
    - port: 7848
      name: old-raft-rpc
      targetPort: 7848
  selector:
    app: nacos
---
apiVersion: v1
kind: Service
metadata:
  name: nacos-svc
  namespace: public
  labels:
    app: nacos
  # annotations:
  # prometheus.io/path: /nacos/actuator/prometheus
  # prometheus.io/port: "8848"
  # prometheus.io/scrape: "true"
  # service.alpha.kubernetes.io/tolerate-unready-endpoints: "true"
spec:
  ports:
    - port: 8848
      name: server
      targetPort: 8848
    - port: 9848
      name: client-rpc
      targetPort: 9848
    - port: 9849
      name: raft-rpc
      targetPort: 9849
    ## 兼容1.4.x版本的选举端口
    - port: 7848
      name: old-raft-rpc
      targetPort: 7848
  type: ClusterIP
  selector:
    app: nacos

ingress.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  annotations:
    # kubernetes.io/ingress.class: "nginx"                   # 这里是ingressclass名字, 老版本k8s用这个
    nginx.ingress.kubernetes.io/ssl-redirect: 'true'
    nginx.ingress.kubernetes.io/app-root: '/nacos'
    # 下面的配置和上面的app-root效果一样，就是跳转到 /nacos
    # nginx.ingress.kubernetes.io/configuration-snippet: |
    #   rewrite ^/$ https://$host/nacos/ redirect;
  name: prod-nacos-ingress
  namespace: public
spec:
  ingressClassName: 'nginx' # 这里是ingressclass名字, 新版本k8s用这个
  rules:
    - host: nacos.k8s.io
      http:
        paths:
          - backend:
              service:
                name: nacos-svc
                port:
                  number: 8848
            path: /
            pathType: ImplementationSpecific

上面这个是 http 的访问， 下面来做一个 https 的访问

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

 cat ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  annotations:
    cert-manager.io/cluster-issuer: letsencrypt-production
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
    nginx.ingress.kubernetes.io/app-root: "/nacos"
  name: prod-nacos-ingress
  namespace: public
spec:
  ingressClassName: "nginx"
  rules:
    - host: nacos.k8s.io
      http:
        paths:
          - backend:
              service:
                name: nacos-svc
                port:
                  number: 8848
            path: /
            pathType: ImplementationSpecific
  tls:
    - hosts:
        - nacos.k8s.io
      secretName: example-com-tls

上面这个是通过 cert-manager.io/cluster-issuer: letsencrypt-production 自动创建证书的。 image.png ![[image-20240820094529870.png]]

nacos.sql

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441

/*

* Copyright 1999-2018 Alibaba Group Holding Ltd.

*

* Licensed under the Apache License, Version 2.0 (the "License");

* you may not use this file except in compliance with the License.

* You may obtain a copy of the License at

*

* http://www.apache.org/licenses/LICENSE-2.0

*

* Unless required by applicable law or agreed to in writing, software

* distributed under the License is distributed on an "AS IS" BASIS,

* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.

* See the License for the specific language governing permissions and

* limitations under the License.

*/



/******************************************/

/* 表名称 = config_info */

/******************************************/

CREATE TABLE `config_info` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) DEFAULT NULL COMMENT 'group_id',

`content` longtext NOT NULL COMMENT 'content',

`md5` varchar(32) DEFAULT NULL COMMENT 'md5',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

`src_user` text COMMENT 'source user',

`src_ip` varchar(50) DEFAULT NULL COMMENT 'source ip',

`app_name` varchar(128) DEFAULT NULL COMMENT 'app_name',

`tenant_id` varchar(128) DEFAULT '' COMMENT '租户字段',

`c_desc` varchar(256) DEFAULT NULL COMMENT 'configuration description',

`c_use` varchar(64) DEFAULT NULL COMMENT 'configuration usage',

`effect` varchar(64) DEFAULT NULL COMMENT '配置生效的描述',

`type` varchar(64) DEFAULT NULL COMMENT '配置的类型',

`c_schema` text COMMENT '配置的模式',

`encrypted_data_key` varchar(1024) NOT NULL DEFAULT '' COMMENT '密钥',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_configinfo_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='config_info';



/******************************************/

/* 表名称 = config_info_aggr */

/******************************************/

CREATE TABLE `config_info_aggr` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) NOT NULL COMMENT 'group_id',

`datum_id` varchar(255) NOT NULL COMMENT 'datum_id',

`content` longtext NOT NULL COMMENT '内容',

`gmt_modified` datetime NOT NULL COMMENT '修改时间',

`app_name` varchar(128) DEFAULT NULL COMMENT 'app_name',

`tenant_id` varchar(128) DEFAULT '' COMMENT '租户字段',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_configinfoaggr_datagrouptenantdatum` (`data_id`,`group_id`,`tenant_id`,`datum_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='增加租户字段';





/******************************************/

/* 表名称 = config_info_beta */

/******************************************/

CREATE TABLE `config_info_beta` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) NOT NULL COMMENT 'group_id',

`app_name` varchar(128) DEFAULT NULL COMMENT 'app_name',

`content` longtext NOT NULL COMMENT 'content',

`beta_ips` varchar(1024) DEFAULT NULL COMMENT 'betaIps',

`md5` varchar(32) DEFAULT NULL COMMENT 'md5',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

`src_user` text COMMENT 'source user',

`src_ip` varchar(50) DEFAULT NULL COMMENT 'source ip',

`tenant_id` varchar(128) DEFAULT '' COMMENT '租户字段',

`encrypted_data_key` varchar(1024) NOT NULL DEFAULT '' COMMENT '密钥',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_configinfobeta_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='config_info_beta';



/******************************************/

/* 表名称 = config_info_tag */

/******************************************/

CREATE TABLE `config_info_tag` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) NOT NULL COMMENT 'group_id',

`tenant_id` varchar(128) DEFAULT '' COMMENT 'tenant_id',

`tag_id` varchar(128) NOT NULL COMMENT 'tag_id',

`app_name` varchar(128) DEFAULT NULL COMMENT 'app_name',

`content` longtext NOT NULL COMMENT 'content',

`md5` varchar(32) DEFAULT NULL COMMENT 'md5',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

`src_user` text COMMENT 'source user',

`src_ip` varchar(50) DEFAULT NULL COMMENT 'source ip',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_configinfotag_datagrouptenanttag` (`data_id`,`group_id`,`tenant_id`,`tag_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='config_info_tag';



/******************************************/

/* 表名称 = config_tags_relation */

/******************************************/

CREATE TABLE `config_tags_relation` (

`id` bigint(20) NOT NULL COMMENT 'id',

`tag_name` varchar(128) NOT NULL COMMENT 'tag_name',

`tag_type` varchar(64) DEFAULT NULL COMMENT 'tag_type',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) NOT NULL COMMENT 'group_id',

`tenant_id` varchar(128) DEFAULT '' COMMENT 'tenant_id',

`nid` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'nid, 自增长标识',

PRIMARY KEY (`nid`),

UNIQUE KEY `uk_configtagrelation_configidtag` (`id`,`tag_name`,`tag_type`),

KEY `idx_tenant_id` (`tenant_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='config_tag_relation';



/******************************************/

/* 表名称 = group_capacity */

/******************************************/

CREATE TABLE `group_capacity` (

`id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT '主键ID',

`group_id` varchar(128) NOT NULL DEFAULT '' COMMENT 'Group ID，空字符表示整个集群',

`quota` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '配额，0表示使用默认值',

`usage` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '使用量',

`max_size` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '单个配置大小上限，单位为字节，0表示使用默认值',

`max_aggr_count` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '聚合子配置最大个数，，0表示使用默认值',

`max_aggr_size` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值',

`max_history_count` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '最大变更历史数量',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_group_id` (`group_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='集群、各Group容量信息表';



/******************************************/

/* 表名称 = his_config_info */

/******************************************/

CREATE TABLE `his_config_info` (

`id` bigint(20) unsigned NOT NULL COMMENT 'id',

`nid` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT 'nid, 自增标识',

`data_id` varchar(255) NOT NULL COMMENT 'data_id',

`group_id` varchar(128) NOT NULL COMMENT 'group_id',

`app_name` varchar(128) DEFAULT NULL COMMENT 'app_name',

`content` longtext NOT NULL COMMENT 'content',

`md5` varchar(32) DEFAULT NULL COMMENT 'md5',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

`src_user` text COMMENT 'source user',

`src_ip` varchar(50) DEFAULT NULL COMMENT 'source ip',

`op_type` char(10) DEFAULT NULL COMMENT 'operation type',

`tenant_id` varchar(128) DEFAULT '' COMMENT '租户字段',

`encrypted_data_key` varchar(1024) NOT NULL DEFAULT '' COMMENT '密钥',

PRIMARY KEY (`nid`),

KEY `idx_gmt_create` (`gmt_create`),

KEY `idx_gmt_modified` (`gmt_modified`),

KEY `idx_did` (`data_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='多租户改造';





/******************************************/

/* 表名称 = tenant_capacity */

/******************************************/

CREATE TABLE `tenant_capacity` (

`id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT '主键ID',

`tenant_id` varchar(128) NOT NULL DEFAULT '' COMMENT 'Tenant ID',

`quota` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '配额，0表示使用默认值',

`usage` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '使用量',

`max_size` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '单个配置大小上限，单位为字节，0表示使用默认值',

`max_aggr_count` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '聚合子配置最大个数',

`max_aggr_size` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值',

`max_history_count` int(10) unsigned NOT NULL DEFAULT '0' COMMENT '最大变更历史数量',

`gmt_create` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '创建时间',

`gmt_modified` datetime NOT NULL DEFAULT CURRENT_TIMESTAMP COMMENT '修改时间',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_tenant_id` (`tenant_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='租户容量信息表';





CREATE TABLE `tenant_info` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`kp` varchar(128) NOT NULL COMMENT 'kp',

`tenant_id` varchar(128) default '' COMMENT 'tenant_id',

`tenant_name` varchar(128) default '' COMMENT 'tenant_name',

`tenant_desc` varchar(256) DEFAULT NULL COMMENT 'tenant_desc',

`create_source` varchar(32) DEFAULT NULL COMMENT 'create_source',

`gmt_create` bigint(20) NOT NULL COMMENT '创建时间',

`gmt_modified` bigint(20) NOT NULL COMMENT '修改时间',

PRIMARY KEY (`id`),

UNIQUE KEY `uk_tenant_info_kptenantid` (`kp`,`tenant_id`),

KEY `idx_tenant_id` (`tenant_id`)

) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT='tenant_info';



CREATE TABLE `users` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`username` varchar(50) NOT NULL COMMENT 'username',

`password` varchar(500) NOT NULL COMMENT 'password',

`enabled` boolean NOT NULL COMMENT 'enabled',

PRIMARY KEY (`id`)

);



CREATE TABLE `roles` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`username` varchar(50) NOT NULL COMMENT 'username',

`role` varchar(50) NOT NULL COMMENT 'role',

PRIMARY KEY (`id`),

UNIQUE INDEX `idx_user_role` (`username` ASC, `role` ASC) USING BTREE

);



CREATE TABLE `permissions` (

`id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT 'id',

`role` varchar(50) NOT NULL COMMENT 'role',

`resource` varchar(128) NOT NULL COMMENT 'resource',

`action` varchar(8) NOT NULL COMMENT 'action',

PRIMARY KEY (`id`),

UNIQUE INDEX `uk_role_permission` (`role`,`resource`,`action`) USING BTREE

);







INSERT INTO users (username, password, enabled) VALUES ('nacos', '$2a$10$EuWPZHzz32dJN7jexM34MOeYirDdFAZm2kuWj7VEOJhhZkDrxfvUu', TRUE);



INSERT INTO roles (username, role) VALUES ('nacos', 'ROLE_ADMIN');
k8s
Licensed under CC BY-NC-SA 4.0
最后更新于 Jan 06, 2025 05:52 UTC
comments powered by Disqus
© 2020 - 2025 卡巴斯之殇
Built with Hugo
主题 Stack 由 Jimmy 设计
#׷
Caret Up
